- Product No. : 6AV2123-2JB03-0AX0
- Product type designation : KTP900 Basic color PN
- Description : SIMATIC HMI, KTP900 Basic, Basic Panel, Key/touch operation, 9″ TFT display, 65536 colors, PROFINET interface, configurable from WinCC Basic V13/ STEP 7 Basic V13, contains open-source software, which is provided free of charge see enclosed CD
- Design of display : TFT widescreen display, LED backlighting
- Screen diagonal : 9 in
- Display width x height : 198 mm x 111.7 mm
- Type of supply voltage : DC
- Rated value (DC) : 24 V
- Permissible range : lower limit (DC) : 19.2 V, upper limit (DC) : 28.8 V
- Current consumption (rated value) : 230 mA
- Starting current inrush I²t : 0.2 A²·s
- Active power input, typ. : 5.5 W
- Processor type : ARM
- Flash : Yes
- RAM : Yes
- Memory available for user data : 10 Mbyte
- Housing front : Width : 267 mm, Height : 182 mm
- Mounting cutout : width : 251 mm, height : 166 mm
- Overall depth : 55 mm
- Weight : 1.130 kg
****************************************
Dongguan JoyTo Technical Co., Ltd is a professional provider of industrial control devices, automation parts and electronic components.
Our company mainly focus is to provide customers with products and solutions for instrumentation, automation and optimization of industrial processes, such as: Programmable logic controller (PLS’s), Variable frequency drives (VFD’s), Human machine interface (HMIs), Motion controllers, Sensors, Low voltage circuit breakers, AC servo motors, Relay, Industrial power supply, Touch screen, IGBT modules, temperature transmitters, pressure transmitters, flow transmitters, flow meters and thermal analysis instruments.
We can source and supply spare parts with short lead times, assisted by our supply partners and from local stocks.
Our aim is to minimise downtime, whilst providing great customer service and technical support.
We have large original brand new stocks , most PLC , inverter , relay , IGBT module , VFD , sensor , encoder , power supply , circuit breaker , contactor , etc.
Welcome to enquiry, we will always support you the best price with perfect quality , fast shipping!
